Intel® Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel® Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.
Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.
| Vægt | 0,0000 kg |
|---|---|
| Forbindelsesteknologi | Ledningsført |
| Brand | Intel |
| State | Default |
| Værtsgrænseflade | PCI Express |
| Grænseflade | Fiber |
| Ethernet LAN-porte (RJ-45) | 1 |
| Maksimal dataoverførselshastighed | 40000 Mbit/s |
| Netværksstandarder | IEEE 802.1Q, IEEE 802.1Qbg, IEEE 802.1as, IEEE 802.1p, IEEE 802.3, IEEE 802.3ad |
| Ethernet-grænsefladetype | 10 Gigabit Ethernet, 40 Gigabit Ethernet |
| Ethernet LAN-datahastigheder | 10000,40000 Mbit/s |
| VLAN mærkning | Ja |
| LAN Kontroller | Intel® XL710 |
| Intern | Ja |
| Produktfarve | Sort, Grøn |
| Kompatible operativsystemer | |
| Driftstemperatur (T-T) | 0 – 55 °C |
| Opbevaringstemperatur (T-T) | -40 – 70 °C |
| Flowkontrol support | Ja |
| Intel® Virtual Machine Device Queues (VMDq) | Ja |
| Intel® Fleksibel Port-deling | Ja |
| Harmoniseret systemkode (HS) | 8517620090 |
| Understøttede Linux-operativsystemer | Ja |
| Relativ luftfugtighed ved opbevaring (H-H) | 0 – 90% |
| Fiberkanal porte | 1 |
| Fiber optisk strømstik | QSFP+ |
| PCI version | 3.0 |
| Fiber ethernet kabelteknologi | 40GBASE-SR4 |
| Maksimal driftstilstand | 7 m |
| Markedssegment | Server |
| Antal VLAN'er | 4096 |
| PCI-SIG* SR-IOV kompetent | Ja |
| On-chip QoS og trafik administration | Ja |
| Speed & slot width | 8.0 GT/s, x8 Lane |
| Muligheder med lav halogen tilgængelig | Ingen |
| Intelligent Offloads | Ja |
| iWARP/RDMA | Ingen |
| Intel® Data Direct I/O Teknologi | Ja |
| Intel® Virtualization Technology for Connectivity (VT-c) | Ja |
| Grænsefladetype | PCIe v3.0 (8.0 GT/s) |
| Produkttype | Network Interface Card |
| Processorserie | 700 Network Adapters (up to 40GbE)-700 Network Adapters (up to 40GbE) |
| Ethernet adapter ARK ID | 96046 |
| Eksportkontrolklassisfikationsnummer (ECCN) | 5A991 |
| Automatiseret sporingssystem til vareklassificering (CCATS) | NA |
| Controller type | Intel® Ethernet Controller XL710 |
| Kabeltype | QSFP+ Direct Attach Copper Cable (Twinaxial)(1-7m) / 40GBASE-SR4 Optics also supported (Purchase Intel branded optics separately) |
| Beslagshøjde | OCP form factor (Mezz 2.0 Design Spec) |
| Målgruppe | Artificial Intelligence, High Performance Computing |
| Opbevaring over ethernet | iSCSI, NFS |
| Lanceringsdato | Q3'16 |
| Netværkskort kabel medium | Copper |
| Netværkskorttype | Server |
| Produktbeskrivelse URL | |
| Status | Launched |
| Sidste ændring | 64826846 |
| Produktfamilie | Intel 10 Gigabit server adapter |
| Produktserie | 700 Series Network Adapters (up to 40GbE) |
| iSCSI-understøttelse | Ja |
| Dataoverførselshastighed | 8 GT/s |
| Balance system | Ja |
