iWARP/RDMA
iWARP delivers converged, low-latency fabric services to data centers through Remote Direct Memory Access (RDMA) over Ethernet. The key iWARP components that deliver low-latency are Kernel Bypass, Direct Data Placement, and Transport Acceleration.
Intel® Data Direct I/O Technology
Intel® Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel® Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.
PCI-SIG* SR-IOV Capable
Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.
Intel® Ethernet Power Management
Intel® Ethernet Power Management Technology provides solutions to common power management approaches by reducing idle power, reducing capacity and power as a function of demand, operating at maximum energy efficiency whenever possible, and enabling functionality only when needed.
Flexible Port Partitioning
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.
Virtual Machine Device Queues (VMDq)
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance
| Vægt | 0,0000 kg |
|---|---|
| Forbindelsesteknologi | Ledningsført |
| Brand | Intel |
| State | Default |
| Værtsgrænseflade | PCI Express |
| Grænseflade | Fiber |
| Ethernet LAN-porte (RJ-45) | 4 |
| Maksimal dataoverførselshastighed | 10000 Mbit/s |
| Ethernet LAN-datahastigheder | 10,1000 Mbit/s |
| LAN Kontroller | Intel® XL710-BM1 |
| Intern | Ja |
| Produktfarve | Sort, Grøn, Rustfrit stål |
| LED-indikatorer | Ja |
| Kompatible operativsystemer | |
| Driftstemperatur (T-T) | 0 – 55 °C |
| Opbevaringstemperatur (T-T) | -40 – 70 °C |
| Bredde | 167 mm |
| Dybde | 111 mm |
| Antal | 1 |
| Intel® Virtual Machine Device Queues (VMDq) | Ja |
| Intel® Fleksibel Port-deling | Ja |
| Harmoniseret systemkode (HS) | 85176990 |
| Relativ luftfugtighed ved drift (H-H) | 0 – 90% |
| Fiberkanal porte | 4 |
| Fiber optisk strømstik | SFP+ |
| PCI version | 3.0 |
| Fiber ethernet kabelteknologi | 10GBASE-LR, 10GBASE-SR |
| Maksimal driftstilstand | 10 m |
| Certificering | FCC A, UL, CE, VCCI, BSMI, CTICK, KCC |
| Markedssegment | Server |
| PCI-SIG* SR-IOV kompetent | Ja |
| On-chip QoS og trafik administration | Ja |
| Lagring over ethernet | Ja |
| Speed & slot width | 8.0 GT/s, x8 Lane |
| Muligheder med lav halogen tilgængelig | Ingen |
| Intelligent Offloads | Ja |
| iWARP/RDMA | Ingen |
| Fiberkanal over ethernet | Ingen |
| Intel® Ethernet Power Administration | Ja |
| Intel® Data Direct I/O Teknologi | Ja |
| Intel® Virtualization Technology for Connectivity (VT-c) | Ja |
| Grænsefladetype | PCIe v3.0 (8.0 GT/s) |
| Konfliktfri | Ja |
| Produkttype | Network Interface Card |
| Processorserie | 700 Network Adapters (up to 40GbE)-700 Network Adapters (up to 40GbE) |
| Ethernet adapter ARK ID | 83965 |
| Eksportkontrolklassisfikationsnummer (ECCN) | 5A991 |
| Automatiseret sporingssystem til vareklassificering (CCATS) | NA |
| Controller type | Intel® Ethernet Controller X710 |
| Kabeltype | SFP+ Direct Attached Twin Axial Cabling up to 10m |
| Beslagshøjde | Full-Height (FH) |
| Målgruppe | Artificial Intelligence, High Performance Computing |
| Opbevaring over ethernet | iSCSI NFS |
| Lanceringsdato | Q4'14 |
| Netværkskort kabel medium | Copper |
| Netværkskorttype | Server |
| Produktbeskrivelse URL | |
| Status | Launched |
| Sidste ændring | 64826826 |
| Produktfamilie | Intel 10 Gigabit server adapter |
| Produktserie | 700 Series Network Adapters (up to 40GbE) |
| Produktkode navn | Fortville |
| Servicekvalitet support (QoS) | Ja |
| Dataoverførselshastighed | 8 GT/s |
