Extended Heatsink
Extended Heatsink enlarges the surface of heat dissipation and maintain the performance at heavy loads.
M.2 Shield Frozr
Strengthened M.2 thermal solution helps M.2 SSD safe and ensures incredible performance.
Heavy Plated VRM Heatsink
The VRM heatsink covers the upper MOS and helps dissipate the heat.
7W/mK Thermal Pad & Additional Choke Pad
High-quality 7W/mK MOSFET thermal pads and additional choke thermal pads ensure stable performance when all cores are running at high speed.
LIGHTNING GEN 5 PCI-E
Doubling over the previous generation, the bandwidth of a x16 interface can reach 128GB/s.
SMT PCIE 5.0 SLOT
The advanced SMT(Surface Mount Technology) PCIE slot diminish interference and electrical noise, fully support the PCI-E 5.0 signal.
REINFORCED,
HEAVY SOLDERED CONNECTIONS
Secure to the motherboard with extra solder points and support the weight of heavy graphics cards.
| Vægt | 1,0500 kg |
|---|---|
| Processorproducent | AMD |
| Brand | MSI |
| State | Default |
| Processor sokkel | Sokkel AM5 |
| Understøttede hukommelsestyper | DDR5-SDRAM |
| Antal hukommelsesstik | 4 |
| Maksimal intern hukommelse | 192 GB |
| Hukommelses slots type | DIMM |
| Hukommelseskanaler | To-kanals |
| USB 2.0-stik | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) stik | 4 |
| Antal SATA III-stik | 4 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 4 |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte | 3 |
| Ethernet LAN-porte (RJ-45) | 1 |
| HDMI-version | 2.1 |
| Ethernet LAN | Ja |
| Ethernet-grænsefladetype | 2.5 Gigabit Ethernet |
| LAN Kontroller | Realtek RTL8125-BG |
| Komponent til | PC |
| Motherboard form faktor | ATX |
| Bundkort chipset familie | AMD |
| Bundkort chipsæt | AMD X670 |
| Lyd-output kanaler | 7.1 kanaler |
| Lydchip | Realtek ALC897 |
| Understøttede Windows-operativsystemer | Windows 10 x64, Windows 11 x64 |
| Antal M.2 (M) slots | 4 |
| BIOS-type | UEFI AMI |
| BIOS-hukommelsesstørrelse | 256 Mbit |
| ACPI-version | 6.4 |
| System Management BIOS (SMBIOS) version | 3.5 |
| Bredde | 243,8 mm |
| Dybde | 304,8 mm |
| Understøttede lagerdrev brugerflader | M.2, SATA III |
| Antal HDMI-porte | 1 |
| Antal DisplayPorts | 1 |
| S/PDIF-udgang | Ja |
| Wi-Fi | Ja |
| RAID-niveauer | 0, 1, 10 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| Bluetooth | Ja |
| Bluetooth-version | 5.3 |
| USB 3.2 Gen 2 (3.1 Gen 2) -stik | 1 |
| DisplayPort-version | 1.4 |
| Understøtter RAID | Ja |
| Bedste Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi-standarder | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Produktfarve | Aluminium, Sort |
| On-board grafikkort | Ingen |
| Antal USB 3.2 Gen 2x2 type-C-porte | 1 |
| PCI Express x16 (Gen 5.x) slots | 2 |
| ECC сompatibility | NON-ECC |
