The LevelOne WAC-2010 is a Gigabit WLAN controller designed for use in small to medium-sized networks in SMEs, schools, guesthouses, hotels, and apartments. Central management of up to 128 APs provides complete wireless security and service solutions for any small to medium-sized wireless network.
The WAC-2010 integrates a variety of features that allow the administrator to easily build the AP configuration. Including tag-based VLAN settings, AP firmware updates, as well as monitoring of the number and status of connected APs and users.
The WAC-2010 controller is also an Internet gateway with a robust firewall to protect against intruders, 1 WAN and 4 LAN ports at Gigabit speed enable fast and reliable data distribution in the network.
The LevelOne WAC-2010 also supports real-time control of signal strength and interference information. With the results, the WAC-2010 automatically regulates network utilization, output power, RF coverage, and channel distribution of APs to optimize wireless coverage, roaming of end devices, and throughput.
| Vægt | 0,0000 kg |
|---|---|
| LED-indikatorer | Aktivitet, Link, Strøm |
| Brand | LevelOne |
| State | Default |
| Kontrolpanel display | Ingen |
| Intern hukommelse | 256 MB |
| Flashhukommelse | 16 MB |
| Ethernet LAN-datahastigheder | 10,100,1000 Mbit/s |
| Netværksstandarder | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Ethernet LAN-porte (RJ-45) | 4 |
| Servicekvalitet support (QoS) | Ja |
| Bredde | 294 mm |
| Dybde | 189 mm |
| Højde | 44 mm |
| Pakkebredde | 325 mm |
| Pakkedybde | 241 mm |
| Pakkehøjde | 81 mm |
| Kabler inkluderet | Vekselstrøm |
| Driftstemperatur (T-T) | -20 – 55 °C |
| Opbevaringstemperatur (T-T) | -40 – 70 °C |
| Relativ luftfugtighed ved drift (H-H) | 10 – 90% |
| Relativ luftfugtighed ved opbevaring (H-H) | 5 – 95% |
| Produktfarve | Sort |
| WAN-forbindelse | Ethernet (RJ-45) |
| Indgangsspænding | 100 – 240 V |
| Vægt | 1,4 kg |
| Pakkevægt | 2,08 kg |
| Indgangsfrekvens | 50/60 Hz |
| Pakketype | Kasse |
| Oprindelsesland | Kina |
| Overholdelse af bæredygtighed | Ja |
| Kabinetmateriale | Metal |
| Kabelteknologi | 10/100/1000Base-T(X) |
| Hurtig start guide | Ja |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
