The PRO Series is tailored to professionals from all walks of life. The lineup features impressive performance and high quality, while aiming to provide users incredible experience. Users who care about productivity and efficiency can definitely count on the MSI PRO Series to assist you with multitasking and increasing efficiency.
LIGHTNING GEN 5 PCI-E
Doubling over the previous generation, the bandwidth of a x16 interface can reach 128GB/s.
SMT PCIE 5.0 SLOT
The advanced SMT(Surface Mount Technology) PCIE slot diminish interference and electrical noise, fully support the PCI-E 5.0 signal.
REINFORCED,
HEAVY SOLDERED CONNECTIONS
Secure to the motherboard with extra solder points and support the weight of heavy graphics cards.
| Vægt | 1,5550 kg |
|---|---|
| Processorproducent | Intel |
| Brand | MSI |
| State | Default |
| Processor sokkel | LGA 1700 |
| Kompatibel processor serie | Intel® Celeron®, Intel® Pentium® Gold |
| Understøttede hukommelsestyper | DDR5-SDRAM |
| Antal hukommelsesstik | 4 |
| Maksimal intern hukommelse | 128 GB |
| Understøttede hukommelsesclock-hastigheder | 4800,5000,5200,5400,5800,6000,6400,6600,6800,7000 MHz |
| Understøttelse af parallel behandlingsteknologi | Ikke understøttet |
| USB 2.0-stik | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) stik | 4 |
| Antal SATA III-stik | 6 |
| Lydstik på frontpanel | Ja |
| Stik til frontpanel | Ja |
| Antal USB 2.0-porte | 4 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 2 |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte | 1 |
| Ethernet LAN-porte (RJ-45) | 1 |
| HDMI-version | 2.1 |
| Ethernet LAN | Ja |
| Ethernet-grænsefladetype | 2.5 Gigabit Ethernet |
| Komponent til | PC |
| Motherboard form faktor | ATX |
| Bundkort chipset familie | Intel |
| Bundkort chipsæt | Intel Z790 |
| Lyd-output kanaler | 7.1 kanaler |
| Lydchip | Realtek ALC897 |
| Understøttede Windows-operativsystemer | Windows 10 x64, Windows 11 x64 |
| Antal M.2 (M) slots | 4 |
| BIOS-type | UEFI AMI |
| BIOS-hukommelsesstørrelse | 256 Mbit |
| System Management BIOS (SMBIOS) version | 3.5 |
| Bredde | 304,8 mm |
| Dybde | 243,8 mm |
| Kabler inkluderet | SATA |
| Understøttede lagerdrev brugerflader | M.2, PCI Express |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) type-C-porte | 1 |
| Antal HDMI-porte | 1 |
| Antal DisplayPorts | 1 |
| S/PDIF-udgang | Ja |
| Wi-Fi | Ja |
| Understøttede procesorsokler | LGA 1700 |
| RAID-niveauer | 0, 1, 5, 10 |
| TPM-stik | Ja |
| Bluetooth | Ja |
| Bluetooth-version | 5.3 |
| Understøttet datalagringsdrev typer | HDD & SSD |
| USB 3.2 Gen 2 (3.1 Gen 2) -stik | 1 |
| DisplayPort-version | 1.4 |
| Header med RGB-LED-ben | Ja |
| Understøtter RAID | Ja |
| Bedste Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi-standarder | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax) |
| Produktfarve | Sort |
| Medfølgende software | DriversMSI CenterIntel Extreme Tuning UtilityCPU-Z MSI GAMINGNorton 360 DeluxeAIDA64 Extreme – MSI Edition |
| On-board grafikkort | Ingen |
| Antal USB 3.2 Gen 2x2 type-C-porte | 1 |
| Understøttet hukommelsesur hastighed (maks.) | 7000 MHz |
| Intern lagerkapacitet | 10 GB |
| ECC сompatibility | NON-ECC |
