PRO series helps users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity.
FULLY CONTROLLABLE IN BIOS AND SOFTWARE
MSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically.
LOW LATENCY GAMING LAN POWERED BY INTEL®
Stay connected with Intel® LAN, optimized for stable internet throughput ideal for championship level online plays.
LIGHTNING GEN 4 PCI-E
MSI lightning Gen 4 PCI-E is the latest and the fastest PCI-E data transfer solution with 64GB/s of transfer bandwidth that has doubled compared to its previous generation. PCIe 4.0 maintains both backward and forward compatibility with older and newer specifications. Optimized by steel armor design, your motherboards can support the weight of heavy graphics cards.
| Vægt | 1,0000 kg |
|---|---|
| Processorproducent | Intel |
| Brand | MSI |
| State | Default |
| Processor sokkel | LGA 1700 |
| Kompatibel processor serie | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium G |
| Understøttede hukommelsestyper | DDR5-SDRAM |
| Antal hukommelsesstik | 4 |
| Maksimal intern hukommelse | 96 GB |
| Hukommelses slots type | DIMM |
| Hukommelseskanaler | To-kanals |
| Understøttede hukommelsesclock-hastigheder | 5600 MHz |
| USB 2.0-stik | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) stik | 2 |
| Antal SATA III-stik | 4 |
| Lydstik på frontpanel | Ja |
| ATX strømstrik (24 stikben) | Ja |
| CPU-ventilatorstik | Ja |
| Antal kabinetventilatorstik | 2 |
| Antal COM-stik | 2 |
| Antal USB 2.0-porte | 4 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 2 |
| Ethernet LAN-porte (RJ-45) | 1 |
| Antal PS/2-porte | 1 |
| HDMI-version | 1.4 |
| Ethernet LAN | Ja |
| Ethernet-grænsefladetype | 2.5 Gigabit Ethernet |
| Komponent til | PC |
| Motherboard form faktor | micro ATX |
| Bundkort chipset familie | Intel |
| Bundkort chipsæt | Intel H610 |
| Lyd-output kanaler | 7.1 kanaler |
| Understøttede Windows-operativsystemer | Windows 10, Windows 11 |
| BIOS-type | UEFI AMI |
| BIOS-hukommelsesstørrelse | 256 Mbit |
| ACPI-version | 6.4 |
| Bredde | 200 mm |
| Dybde | 236,2 mm |
| Kabler inkluderet | SATA |
| Drivere inkluderet | Ja |
| Understøttede lagerdrev brugerflader | M.2, SATA III |
| Antal HDMI-porte | 1 |
| Udgange til hovedtelefoner | 2 |
| Wi-Fi | Ingen |
| Understøttede procesorsokler | LGA 1700 |
| RAID-niveauer | 0, 1, 5, 10 |
| EPS strømstik (8-pin) | Ja |
| PCI Ekspres x1 (Gen 3.x) slots | 2 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| Understøttet datalagringsdrev typer | HDD & SSD |
| Thunderbolt-headere | 2 |
| Mikrofonindgang | Ja |
| Kølingstype | Aktiv |
| Strømkilde type | ATX |
| Ikke-fejlkorrigerende kode | Ja |
| Understøtter RAID | Ja |
| Antal VGA-porte (D-sub) | 1 |
| Lydstik | Ja |
| Understøttede hukommelsesmodulkapaciteter | 4GB, 8GB, 16GB, 32GB |
| ECC сompatibility | NON-ECC |
