Create a high-resolution 4k x 2k connection with HBR2 support between your Mini DisplayPort™-equipped laptop and a standard DP monitor
The MDP2DPMM1MW 1m White Mini DisplayPort™ to DisplayPort Adapter Cable, features a Mini DP male connector on one end, and a DP male connector on the other, allowing you to connect any Mini DisplayPort-equipped laptop (including the Mac® family of products) to an HDTV, monitor or projector that uses a standard DisplayPort connection.
The mDP to DP cable supports high resolutions of up to 4k x 2k (3840 x 2160) @ 60Hz with a maximum HBR2 bandwidth of 21.6 Gbps. The cable also supports Multi-Stream (MST) for daisy chaining multiple monitors and provides optional audio support.
The MDP2DPMM1MW is backed by StarTech.com’s Lifetime Warranty, for guaranteed reliability and ensures that digitally protected content is displayed properly, with both HDCP and DPCP capability.
Please Note : Newer laptop and desktop computers (e.g. Apple®) come equipped with Thunderbolt™ ports only. Our Mini DP to DP Cables can be connected to the Thunderbolt ports, enabling you to connect your DP compatible displays.
The StarTech.com Advantage
| Vægt | 0,0480 kg |
|---|---|
| Kabellængde | 1 m |
| Brand | StarTech.com |
| State | Default |
| Stik 1 | DisplayPort |
| Stik 2 | Mini DisplayPort |
| Stik 1 køn | Hanstik |
| Stik 2 køn | Hanstik |
| Maksimal opløsning | 3840 x 2400 pixel |
| Produktfarve | Hvid |
| Stik 1 formfaktor | Lige |
| Stik 2 formfaktor | Lige |
| Stikforbindelse kontakter plettering | Guld |
| DisplayPort-version | 1.2 |
| Vægt | 40 g |
| Harmoniseret systemkode (HS) | 84733080 |
| Maksimal opdateringshastighed | 120 Hz |
| Produkter pr. hovedkasse (udvendigt) | 150 stk |
| Understøttede grafikopløsninger | 3840 x 2400, 2560 x 1600 (WQXGA) |
| Kabel vurdering | CMG (CM) |
| Kabelafskærmning | Aluminium mylar folie |
| Materiale for kapper | Polyvinylchlorid (PVC) |
| AWG-ledningsstørrelse | 32 |
| Båndbredde | 21600 MB/s |
| Plug and play | Ja |
| Multi-Stream Transport (MST) | Ja |
| Antal ledere | 19 |
| Pakkebredde | 192 mm |
| Pakkedybde | 143 mm |
| Pakkehøjde | 20 mm |
| Pakkevægt | 50 g |
| Hovedkassens bredde (udvendigt) | 372 mm |
| Hovedkassens længde (udvendigt) | 411 mm |
| Hovedkassen højde (udvendigt) | 273 mm |
| Compliance certificates | RoHS, CE |
