REBELLIOUS AND DISCREET
The MAG CORELIQUID P Series liquid coolers’ water block is not the typical design you frequently see in the market today. It is modest and discreet, but with great quality. It is split into four pieces of unique diamond-cut areas, with three constructed in piano black and the last one featuring our proud MSI logo emblem.
LGA 1700 COMPATIBLE
The MAG CORELIQUID P Series liquid cooler provides out of box support for LGA 1700.
RADIATOR PUMP DESIGN
The pump has been integrated into the radiator for sound dampening and noise reduction. Additionally, placing the pump into the radiator also increases the pump’s life expectancy by moving it away from the heat source.
HIGH THERMAL DISSIPATION
A split pathway through the radiator rapidly dissipates heat, cooled liquid is then pumped back into the loop.
PUMP MOTOR RESONANCE ELIMINATION
A durable three phase motor at the core of the pump generates minimal vibrations for long-lasting operation.
EVAPORATION PROOF TUBING
Constructed with three layers of netted plastic tubing and a reinforced mesh exterior.
EXTENSIVE COMPATIBILITY
Stylish yet built for flexibility, the MAG CORELIQUID P Series has been designed with a secure installation bundle with compatibility on a number of Intel and AMD motherboards.
| Vægt | 1,9500 kg |
|---|---|
| Passende til rumtype | Processor |
| Brand | MSI |
| State | Default |
| Type | Alt-i-en væskekøler |
| Produktfarve | Sort |
| Harmoniseret systemkode (HS) | 84733080 |
| Ventilator diameter | 12 cm |
| Understøttede procesorsokler | LGA 1150 (stik H3), LGA 1151 (stik H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 2011-v3 (Socket R), LGA 2066, Sokkel AM2, Sokkel AM2+, Sokkel AM3, Socket AM3+, Stik AM4, Socket FM1, Socket FM2, Socket FM2+ |
| Oprindelsesland | Kina |
| Maksimal luftstrøm | 78,73 kubikfod/min. |
| Understøttelse af puls-bredde modulering (PWM) | Ja |
| Lejetype | Dobbelt kugleleje |
| Materiale | Aluminium |
| Antal blæsere | 2 blæser(e) |
| Ventilatorstik | 4-pin + 4-pin |
| Ventilator dimensioner (BxDxH) | 120 x 120 x 25 mm |
| Ventilatorens støjniveau (min.) | 14,3 dB |
| Ventilatorens støjniveau (maks.) | 34,3 dB |
| Ventilatorlejeteknologi | Dobbelt kugleleje |
| Pumpemotor hastighed | 4200 rpm |
| Blæser, hastighed (maks.) | 2000 rpm |
| Ventilatorens middeltid til fejl (MTTF) | 70000 t |
| Køler materiale | Aluminium |
| Belysning LED | Ja |
| Ventilator strømforbrug | 1,8 W |
| Blæser, spænding | 12 V |
| Ventilatorstrøm | 0,15 A |
| Køler bredde | 27,6 cm |
| Køler dybde | 12 cm |
| Køler højde | 2,7 cm |
| Rørlængde | 40 cm |
| Pumpespænding | 12 V |
| Blæser, hastighed (min.) | 500 rpm |
| Pumpens effektforbrug | 4,08 W |
| Pumpestrøm | 0,34 mA |
| Vandblok bredde | 7,05 cm |
| Vandblok dybde | 5,2 cm |
| Vandblok højde | 7,05 cm |
| Ventilator statisk tryk | 2,39 mmH2O |
| Støjniveau | 14,3 dB |
| Pumpens middeltid til fejl (MTTF) | 100000 t |
