NEXT-GEN AMD SOCKET AM5 SUPPORT
AMD Socket AM5 (LGA 1718) is the next-generation socket designed to support next-generation AMD Ryzen™ 7000 desktop processors (Zen 4). AMD Socket AM5 uses the same liquid cooler bracket as Socket AM4*. This allows you to upgrade to and enjoy AM5 without buying a new liquid cooler.
POWERED BY MSI
Create and establish the most powerful setup with Powered by MSI products, including PC case, motherboard, liquid cooler, graphics card, and power supply unit.
PUMP MOTOR RESONANCE ELIMINATION
A durable three phase motor at the core of the pump generates minimal vibrations for long-lasting operation.
RADIATOR PUMP DESIGN
The pump has been integrated into the radiator for sound dampening and noise reduction. Additionally, placing the pump into the radiator also increases the pump’s life expectancy by moving it away from the heat source.
EXTENSIVE COMPATIBILITY
Robust yet built for flexibility, MAG CORELIQUID has been designed with a secure installation bundle with compatibility on a number of Intel and AMD motherboards.
ROTATABLE BLOCKHEAD
Mount the cold plate at any orientation, turn the blockhead up to 270 degrees, and keep it upright.
| Vægt | 0,0000 kg |
|---|---|
| Passende til rumtype | Bundkort, Processor |
| Brand | MSI |
| State | Default |
| Type | Væskekølingssæt |
| Produktfarve | Hvid |
| Harmoniseret systemkode (HS) | 84733080 |
| Ventilator diameter | 12 cm |
| Understøttede procesorsokler | LGA 1150 (stik H3), LGA 1151 (stik H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 1700, LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, Sokkel AM |
| Maksimal luftstrøm | 78,73 kubikfod/min. |
| Maksimalt lufttryk | 2,39 mmH2O |
| Understøttelse af puls-bredde modulering (PWM) | Ja |
| Antal blæsere | 3 blæser(e) |
| Ventilatorstik | 4-polet |
| Ventilator dimensioner (BxDxH) | 120 x 120 x 25 mm |
| Kompatibel processor serie | AMD Ryzen 7 5th Gen, 3rd Generation AMD Ryzen™ 9, AMD Ryzen 9 5th Gen, AMD Ryzen Threadripper 3. gen, Intel® Core™ i7, Intel® Core™ i9 |
| Mindste luftmængde | 21,63 kubikfod/min. |
| Ventilatorens støjniveau (min.) | 14,3 dB |
| Ventilatorens støjniveau (maks.) | 34,3 dB |
| Ventilatorlejeteknologi | Kugleleje |
| Pumpestik | 3-stikben |
| Pumpemotor hastighed | 4200 rpm |
| Blæser, hastighed (maks.) | 2000 rpm |
| Køler materiale | Aluminium |
| Belysning LED | Ja |
| Ventilator strømforbrug | 1,8 W |
| Blæser, spænding | 12 V |
| Ventilatorstrøm | 0,15 A |
| Køler bredde | 39,4 cm |
| Køler dybde | 12 cm |
| Køler højde | 2,7 cm |
| Rørlængde | 40 cm |
| Pumpespænding | 12 V |
| Minimum lufttryk | 0,23 mmH2O |
| Blæser 2, diameter | 12 cm |
| Pumpe støjniveau | 18 dB |
| Pumpelejeteknologi | Keramisk leje |
| Blæser, hastighed (min.) | 500 rpm |
| Pumpens effektforbrug | 4,08 W |
| Pumpestrøm | 340 mA |
| Vandblok bredde | 8,06 cm |
| Vandblok dybde | 6,68 cm |
| Vandblok højde | 4,86 cm |
