Connect up to 8 different GbE (4 PoE+) devices, using this IP30 industrial Ethernet switch with intelligent Layer 2 managementEasily deploy or scale your network with this Gigabit Ethernet switch, by adding eight copper Gigabit Ethernet (GbE) connections, including four PoE+ ports. This IP30 industrial network switch provides intelligent Layer 2 management. Its rugged, compact design and wall-mount option with front access make it ideal for demanding applications, even where space is limited.Expand your networkThis Gigabit Ethernet switch lets you expand your network by connecting up to eight RJ45 devices (four PoE+). The 8-port switch enables up to eight users to share files and devices, such as printers and scanners, over a LAN connection, by enhancing your existing network capacity with additional ports.Supports PoE+ for flexible useThe switch gives you the freedom to place your equipment in locations where power outlets are not available, with support for Power over Ethernet Plus. The network switch provides abundant PoE power, with up to 30 watts for each PoE port (120W budget).Wall-mountable with front accessWith its compact design, you can wall-mount the Gigabit switch to provide convenient front access to ports and indicators. It’s ideal for a wide range of applications, including tight installation areas with significant electromagnetic interference, such as control cabinets and panels. The network switch is also DIN-rail mountable.Efficient Layer 2 managementThe switch delivers efficient and stable performance, with Layer 2 management capabilities. This lets you control packet traffic on a busy network, and customize your settings to achieve optimal network performance, offering improved efficiency and reliability.Rugged industrial designThis rugged network switch features an IP30-rated metal housing and extended operating temperature range of -40°C to 75°C, which makes it ideal for a wide range of conditions. The sturdy metal enclosure offers durability, even in harsh industrial environments.Reliable connection for seamless network performanceWith support for 10/100/1000Mbps transfer speeds, this managed switch supports full/half-duplex auto-negotiation, jumbo frames, and auto MDI/MDIX operation. This lets you connect your network devices quickly and easily, with little to no configuration required.To help prevent any unnecessary downtime, the switch features redundant 12-58V DC terminal block power inputs, which ensures seamless operation in the event of power dips or failures.The IES81GPOEW is backed by a StarTech.com 2-year warranty and free lifetime technical support.The StarTech.com Advantage
Produktkategori
Lager status
Brand
Valgte filtre
StarTech.com IES81GPOEW netværksswitch Administreret L2 Gigabit Ethernet (10/100/1000) Strøm over Ethernet (PoE) Sort
4.020,00 DKK inkl. moms (ex. moms 3.216,00 DKK)
Få besked når den er på lager
Giv mig besked når varen kan købes
Vægt | 0,0000 kg |
---|---|
Switch-type | Administreret |
Brand | StarTech.com |
State | Default |
Basis omskiftning RJ-45 Ethernet porte, antal | 8 |
Basis omskiftning RJ-45 Ethernet porttype | Gigabit Ethernet (10/100/1000) |
Strømstik | DC-in-stik |
Netværksstandarder | IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3z |
Fuld duplex | Ja |
Flowkontrol support | Ja |
Link aggregering | Ja |
Auto MDI/MDI-X | Ja |
Opbevar-og-frem | Ja |
Jumbo Frames support | Ja |
Jumbo rammer | 9000 |
Stativ-montering | Ingen |
Produktfarve | Sort |
Husmateriale | Stål |
Bufferstørrelse | 512 KB |
Indgangsstrøm | 1 A |
Strøm over Ethernet (PoE) | Ja |
Power over Ethernet plus (PoE+) porte, antal | 4 |
Total Power over Ethernet (PoE) | 120 W |
Driftstemperatur (T-T) | -40 – 75 °C |
Opbevaringstemperatur (T-T) | -40 – 90 °C |
Relativ luftfugtighed ved drift (H-H) | 5 – 95% |
Bredde | 148 mm |
Dybde | 134 mm |
Højde | 25 mm |
Vægt | 650 g |
Pakkebredde | 173 mm |
Pakkedybde | 30 mm |
Pakkehøjde | 92 mm |
Pakkevægt | 930 g |
Harmoniseret systemkode (HS) | 85176990 |
Switch lag | L2 |
10G understøttelse | Ingen |
Vituelle LAN funktioner | Tagged VLAN |
LED-indikatorer | Aktivitet, Link, Strøm |
Certificering | CE, FCC, RoHS |
Gennemsnitstid mellem fejl (MTBF) | 100000 t |
Adgangskontrolliste (ACL) | Ja |
Spanning tree protokol | Ja |
Hurtig start guide | Ja |
Hovedkassens bredde (udvendigt) | 335 mm |
Hovedkassens længde (udvendigt) | 363 mm |
Hovedkassen højde (udvendigt) | 475 mm |
Produkter pr. hovedkasse (udvendigt) | 10 stk |
Kan monteres på væggen | Ja |
Kode for international beskyttelse (IP) | IP30 |
Power over Ethernet (PoE) effekt pr. port | 30 W |
Indgangsspænding | 12 – 48 V |
Strømstiktype | Type M |
Klemrække port | Ja |
Klemrække inkluderet | Ja |
Maksimal dataoverførselshastighed | 2000 Mbit/s |
