LevelOne FEP-1612 features 16 10/100Mbps Fast Ethernet ports with IEEE 802.3at/af PoE interfaces. It supports MDI / MDI-X convertible on 16 10/100Mbps ports and provides PoE inject function on PoE ports which are able to IEEE 802.3af or 802.3at compliant powered devices remotely.
The FEP-1612 equipped with the MDI/MDI-X auto detection for easily plug and play connection, regardless of cabling types in straight through or crossover. It also provides a simple, cost-effective, and highly reliable network connection for data and power transmission. Furthermore, it is the ideal device for bridging among Ethernet, Fast Ethernet workgroups and networks. It fits all kind of Ethernet installations such as campus, workgroup, department, enterprise, telecom or industrial applications.
The FEP-1612 features non-blocking 3.2Gbps backplane that greatly simplifies the tasks of upgrading your LAN for catering to increase bandwidth demands.
– IEEE 802.3af/at PoE compliant to simplify deployment and installation
– Auto-detection and protection of non-standard PoE devices
– Supports 4K MAC address auto-learning and auto-aging
– 10/100Mbps-Full/Half-duplex, Auto-Negotiation, Auto-MDI/MDIX
– 19-inch metal housing
– IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
– Total PoE power budget: 480W, up to 30W per port
| Vægt | 2,0000 kg |
|---|---|
| Switch-type | Ikke administreret |
| Brand | LevelOne |
| State | Default |
| Basis omskiftning RJ-45 Ethernet porte, antal | 16 |
| Basis omskiftning RJ-45 Ethernet porttype | Fast Ethernet (10/100) |
| Netværksstandarder | IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
| Fuld duplex | Ja |
| Auto MDI/MDI-X | Ja |
| MAC adresselabel | 4096 entries |
| Switch kapacitet | 3,2 Gbit/sek. |
| Opbevar-og-frem | Ja |
| Stativ-montering | Ja |
| Produktfarve | Grå |
| Bufferstørrelse | 160 KB |
| Indgangsstrøm | 5 A |
| Strøm over Ethernet (PoE) | Ja |
| Power over Ethernet plus (PoE+) porte, antal | 16 |
| Total Power over Ethernet (PoE) | 480 W |
| Driftstemperatur (T-T) | 0 – 45 °C |
| Opbevaringstemperatur (T-T) | -40 – 70 °C |
| Relativ luftfugtighed ved drift (H-H) | 10 – 90% |
| Relativ luftfugtighed ved opbevaring (H-H) | 10 – 90% |
| Bredde | 200 mm |
| Dybde | 480 mm |
| Højde | 44 mm |
| Vægt | 2,85 kg |
| Pakkebredde | 260 mm |
| Pakkedybde | 535 mm |
| Pakkehøjde | 90 mm |
| Pakkevægt | 3,7 kg |
| Harmoniseret systemkode (HS) | 85176990 |
| 10G understøttelse | Ingen |
| LED-indikatorer | Aktivitet, LAN, PoE, Strøm |
| Certificering | FCC, CE |
| Vekselstrømsindgangsspænding | 100 – 240 V |
| Vekselstrømsindgangsfrekvens | 50 – 60 Hz |
| Stabelbar | Ingen |
| Strømforbrug (typisk) | 500 W |
| Auto-forhandling | Ja |
| Kabler inkluderet | Vekselstrøm |
| Hurtig start guide | Ja |
| Kobber ethernet kabelteknologi | 10BASE-T, 100BASE-TX |
| Understøttede kabeltyper | Cat5 |
| Pakke videresendelsesrate (100 Mbps) | 148000 pps |
| Pakke videresendelsesrate (10 Mbps) | 14880 pps |
| Oprindelsesland | Taiwan |
