Powerful and flexible networking solution for small, medium, and enterprise businesses.
Simple. Easy. Smart
WebUI Web UI
Easy to use web interface to access management features.
Static Routing VLANs
Segment your network into VLANs.
Surveillance mode Surveillance Mode Interface
Get a snapshot of your security topology in an instant.
Advanced Security Features
The DGS-1100 series’ web user interface gives administrators an easy way to manage Layer 2 features, such as VLANs, Spanning Tree Protocol (STP), and link aggregation (desktop models utilize Static Trunk). With powerful security features including IGMP snooping, Static MAC, and Storm Control, these smart managed switches are a versatile solution for deployments that require easy to configure functionality without added complexities.
Simplify Network Management
D-Link’s free Network Assistant (DNA) utility displays all your connected devices and makes first-time configuration a breeze. The free D-View 7 Network Management System comes with a license for 25 nodes and 2 probes and full access to the management tools.
Full PoE Support
The DGS-1100-08PV2 supports IEEE 802.3af/at Power over Ethernet on all eight copper access ports. Power over Ethernet greatly simplifies the installation of PoE-enabled devices such as VoIP phones and IP cameras in remote locations with no immediate access to a power outlet. Each individual port has capacity to support up to 30W of PoE power, while the switch has an overall budget of 64W.
Easy Troubleshooting
The DGS-1100 Series features Loopback Detection and Cable Diagnostics to help network administrators find and solve network problems quickly and easily.
Loopback Detection detects loops created by a specific port and automatically shuts down the affected port. The Cable Diagnostics feature is designed for network administrators to quickly examine the quality of the copper cables, recognize the cable type, and detect cable errors.
Green Technology
D-Link Green technology enables the DGS-1100 Smart Managed Switches to save power without sacrificing performance. The desktop models in the series utilize a fanless design, for silent and energy-efficient operation. All models are also IEEE 802.3az-compliant and feature Link Status detection.
| Vægt | 0,0000 kg |
|---|---|
| Switch-type | Administreret |
| Brand | D-Link |
| State | Default |
| Servicekvalitet support (QoS) | Ja |
| Webbaseret administration | Ja |
| Basis omskiftning RJ-45 Ethernet porte, antal | 8 |
| Basis omskiftning RJ-45 Ethernet porttype | Gigabit Ethernet (10/100/1000) |
| Netværksstandarder | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u |
| Port-spejlning | Ja |
| Fuld duplex | Ja |
| Flowkontrol support | Ja |
| Link aggregering | Ja |
| Broadcast stormkontrol | Ja |
| Auto MDI/MDI-X | Ja |
| MAC adresselabel | 4096 entries |
| Switch kapacitet | 16 Gbit/sek. |
| Jumbo Frames support | Ja |
| Jumbo rammer | 9216 |
| IGMP snooping | Ja |
| Loop beskyttelse | Ja |
| Stativ-montering | Ingen |
| Produktfarve | Sort |
| Strømforbrug (maks.) | 77,9 W |
| Strøm over Ethernet (PoE) | Ja |
| Power over Ethernet plus (PoE+) porte, antal | 8 |
| Total Power over Ethernet (PoE) | 64 W |
| Driftstemperatur (T-T) | 0 – 40 °C |
| Opbevaringstemperatur (T-T) | -40 – 70 °C |
| Relativ luftfugtighed ved drift (H-H) | 0 – 90% |
| Relativ luftfugtighed ved opbevaring (H-H) | 0 – 95% |
| Bredde | 171 mm |
| Dybde | 97,8 mm |
| Højde | 28,6 mm |
| Vægt | 430 g |
| Switch lag | L2/L3 |
| 10G understøttelse | Ingen |
| VLAN understøttelse | Ja |
| Vituelle LAN funktioner | Port-based VLAN, Tagged VLAN, Voice VLAN |
| Antal VLAN'er | 4094 |
| LED-indikatorer | Ja |
| Certificering | FCC Class B, CE Class B, VCCI Class B, BSMIcUL, CE LVD, CB, BSMI |
| Gennemsnitstid mellem fejl (MTBF) | 786841 t |
| Vekselstrømsindgangsspænding | 100 – 240 V |
| Varmeafgivelse | 265,85 BUT/t |
| Hastighed for videresendelse | 11,9 Mpps |
| Multicast-understøttelse | Ja |
| Flashhukommelse | 2 MB |
| Strømforsyning inkluderet | Ja |
| Gigabit Ethernet (kobber) porte, antal | 8 |
| Kobber ethernet kabelteknologi | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Antal køer | 4 |
| Ventilatorfri | Ja |
| Power over Ethernet (PoE) effekt pr. port | 30 W |
| Ethernet LAN-datahastigheder | 10,100,1000 Mbit/s |
| Halv dupleks | Ja |
| Algoritmer for køplanlægning | SP, Weighted Round Robin (WRR) |
| Overholdelse af bæredygtighed | Ja |
| Compliance certificates | CE, RoHS |
