FULLY CONTROLLABLE IN BIOS AND SOFTWARE
MSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically.
FAST AND FUTURE-READY STORAGE
MSI B550 motherboards support all the latest storage standards, which allows users to connect any ultra-fast storage device. Higher efficiency makes your work easier.
DEDICATED HIGH DEFINITION AUDIO PROCESSOR
Make sure you enjoy the purest sound quality in both stereo and surround sound.
HIGH QUALITY AUDIO CAPACITORS
A high fidelity sound experience with exceptional acoustics and realism for studio level headphones is ensured.
HIGH QUALITY AUDIO JACKS
Keep your sound perfect by transmit your audio with pure digital signal.
| Vægt | 1,2700 kg |
|---|---|
| Processorproducent | AMD |
| Brand | MSI |
| State | Default |
| Processor sokkel | Stik AM4 |
| Kompatibel processor serie | AMD Ryzen 3000 Series |
| Maksimalt antal SMP-processorer | 1 |
| Understøttede hukommelsestyper | DDR4-SDRAM |
| Antal hukommelsesstik | 4 |
| Maksimal intern hukommelse | 128 GB |
| Hukommelses slots type | DIMM |
| Hukommelseskanaler | To-kanals |
| Understøttede hukommelsesclock-hastigheder | 1866,2133,2400,2667,2800,2933,3000,3066,3200,3466,3600,3733,3866,4000,4133,4266,4400 MHz |
| Ikke-bufferet hukommelse | Ja |
| Maksimal opløsning | 4096 x 2160 pixel |
| USB 2.0-stik | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) stik | 2 |
| Antal SATA III-stik | 6 |
| Lydstik på frontpanel | Ja |
| ATX strømstrik (24 stikben) | Ja |
| CPU-ventilatorstik | Ja |
| Antal kabinetventilatorstik | 2 |
| 12V strømstik | Ja |
| Antal USB 2.0-porte | 2 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 2 |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte | 1 |
| Ethernet LAN-porte (RJ-45) | 1 |
| Antal DVI-D-porte | 1 |
| Antal PS/2-porte | 1 |
| HDMI-version | 2.0b |
| Ethernet LAN | Ja |
| Ethernet-grænsefladetype | Gigabit Ethernet |
| LAN Kontroller | Realtek RTL8111H |
| Komponent til | PC |
| Motherboard form faktor | ATX |
| Bundkort chipset familie | AMD |
| Bundkort chipsæt | AMD B550 |
| Lyd-output kanaler | 7.1 kanaler |
| Lydchip | Realtek ALC897 |
| Antal M.2 (M) slots | 1 |
| BIOS-type | UEFI AMI |
| BIOS-hukommelsesstørrelse | 256 Mbit |
| Nulstil CMOS-jumper | Ja |
| Bredde | 305 mm |
| Dybde | 244 mm |
| Kabler inkluderet | SATA |
| Drivere inkluderet | Ja |
| Understøttede lagerdrev brugerflader | SATA III |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) type-C-porte | 1 |
| Antal HDMI-porte | 1 |
| S/PDIF-udgang | Ja |
| Wi-Fi | Ingen |
| RAID-niveauer | 0, 1, 10 |
| Bluetooth | Ingen |
| Maksimal grafikadapterhukommelse | 16000 MB |
| Indbrudsttik til kabinet | Ja |
| Header med RGB-LED-ben | Ja |
| Produktfarve | Sort |
| Digital akustisk og optisk udgang | 1 |
| On-board grafikkort | Ingen |
| PCI Ekspres x1 slots | 4 |
| PCI Express x16 slots | 2 |
| ECC сompatibility | NON-ECC |
