B760M-K
ASUS Prime series motherboards are expertly engineered to unleash the full potential of 13th Gen Intel® Core™ Processors. Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, PRIME B760M-K provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features.
FLEXIBILITY
Comprehensive controls form the foundation of the ASUS PRIME series. The PRIME B760 motherboard packs flexible tools to tune every aspect of your system, enabling performance tweaks to perfectly match the way you work to maximize productivity.
Intelligent Control
ASUS Intelligent Control makes your PC smart. Along with taking care of complex tuning and dynamically optimizing essential aspects of your system, it offers intelligently simplified options for newcomers to PC DIY, as well as more comprehensive features for seasoned veterans.
All-Around Energy Efficiency
The Power Saving function contains several settings can easily optimize power consumption and maximize energy savings. You can enable a CPU power limit, darken Aura lighting, and set the fan profile to a power saving mode. You can also toggle the Power Saver plan that is built into Microsoft Windows.
| Vægt | 0,5510 kg |
|---|---|
| Processorproducent | Intel |
| Brand | ASUS |
| State | Default |
| Processor sokkel | LGA 1700 |
| Kompatibel processor serie | Intel® Celeron®, Intel® Pentium® Gold, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9 |
| Maksimalt antal SMP-processorer | 1 |
| Understøttede hukommelsestyper | DDR5-SDRAM |
| Antal hukommelsesstik | 2 |
| Maksimal intern hukommelse | 96 GB |
| Hukommelses slots type | DIMM |
| Hukommelseskanaler | To-kanals |
| Understøttede hukommelsesclock-hastigheder | 7800,7600,7400,7200,7000,6800,6600,6400,6200,6000,5800,5600,5400,5200,5000,4800,8000 MHz |
| Ikke-bufferet hukommelse | Ja |
| Understøttelse af parallel behandlingsteknologi | Ikke understøttet |
| USB 2.0-stik | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) stik | 1 |
| Antal SATA III-stik | 4 |
| Lydstik på frontpanel | Ja |
| ATX strømstrik (24 stikben) | Ja |
| CPU-ventilatorstik | Ja |
| Antal kabinetventilatorstik | 1 |
| Antal COM-stik | 1 |
| 12V strømstik | Ja |
| Antal USB 2.0-porte | 2 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 4 |
| Ethernet LAN-porte (RJ-45) | 1 |
| Antal PS/2-porte | 1 |
| Ethernet LAN | Ja |
| Ethernet-grænsefladetype | 2.5 Gigabit Ethernet |
| Komponent til | PC |
| Motherboard form faktor | micro ATX |
| Bundkort chipset familie | Intel |
| Bundkort chipsæt | Intel B760 |
| Lyd-output kanaler | 7.1 kanaler |
| Understøttede Windows-operativsystemer | Windows 10 x64, Windows 11 |
| Antal M.2 (M) slots | 2 |
| BIOS-type | UEFI AMI |
| BIOS-hukommelsesstørrelse | 128 Mbit |
| Bredde | 244 mm |
| Dybde | 211 mm |
| Kabler inkluderet | SATA |
| Understøttede lagerdrev brugerflader | M.2, SATA III |
| Antal HDMI-porte | 1 |
| S/PDIF-udgang | Ja |
| Wi-Fi | Ingen |
| Understøttede procesorsokler | LGA 1700 |
| RAID-niveauer | 0, 1, 5, 10 |
| EPS strømstik (8-pin) | Ja |
| TPM-stik | Ja |
| PCI Express x16 (Gen 4.x) slots | 1 |
| Understøttet datalagringsdrev typer | HDD & SSD |
| Antal understøttede HHD'er | 4 |
| Header med RGB-LED-ben | Ja |
| Understøtter RAID | Ja |
| Antal VGA-porte (D-sub) | 1 |
| Antal understøttede lagerdiske | 6 |
| S/PDIF-udgangsstik | Ja |
| PCI Express x1 (Gen 4.x) slots | 2 |
| Understøttet hukommelsesur hastighed (maks.) | 8000 MHz |
| ECC сompatibility | NON-ECC |
